ATV Winch/UTV Winch
HS:8425319000
Rated line pull(Single line) 3000lbs(1361kg)
Moter 0.9kw,1.2HP 12V DC Permannent Magnet
Gearing Differrntial planetary
Gear Ratio 153:1
Freespooling clutch Pulland turn
Braking Action Dynamic
Wire Rope Ω5.5mm×8m7/32"×26")
Dimensions 300mm(L)×110mm(W)×105mm(H)
Drum Diameter 1.25"(31.75mm)
Drum Length 3.9"(74mm)
N.W/G.W. 36kg/37kg(4pcs)
Meas 56×38×36cm(4pcs)
Pull,Speed,Amperes,Volts(First layer)
| Line Pull (Ibs./kg) | Line Speed FPM(m/min) | Motor(Amps) |
| 0 | 10.8ft(3.3m) | 12 |
| 1000(454) | 8.2ft(2.5m) | 40 |
| 2000(907) | 3.6ft(1.1m) | 80 |
| 3000(1361) | 2.6ft(0.8m) | 120 |
Line Pull And Rope Capacity In Layer
| Layer | Rated Line Pull(Ibs./kg) | Tatal Rope On Drum(ft/m) |
| 1 | 3000(1361) | 4.9(1.5) |
| 2 | 2320(1052) | 11.5(3.5) |
| 3 | 1890(858) | 19.3(5.9) |
| 4 | 1590(720) | 28.5(8.7) |
| 5 | 1380(620) | 30.0(10) |
